Ceramic Grinding Balls Inert Ceramic Media Balls Alumina Insert
Ceramic Balls
1. Inert Ceramic Balls Name
Ceramic Balls
Alumina Balls
High alumina Balls
Ceramic Alumina Balls
Alumina Grinding Balls
Grinding Media Alumina
Ceramic Grinding Media
Alumina Balls For Ball Mill
High Alumina Bricks
High Alumina Linings
Ceramic Bricks
Ceramic Linings
2. Inert Ceramic Balls Application
Inert ceramic products including ceramic balls, rasching ring and
unshaped catalyst support media. Be widely used in chemical
factory, fiber factory, ethylene plant, gas, oil, chemical
engineering for ball filter, tower bottom filler material and
carrier for catalyst. It has high temperature resistance, high
pressure resistance, low water absorption and stable chemical
performance can work with strongly acid and alkali and adapt to
different temperature change.
3. Inert Ceramic Balls Manufacturing process
Inert ceramic ball is made from alumina ultrafine powder as
principal raw material with advanced technology and high
temperature in tunnel kiln
It have the performance of high purity, high strength and high
temperature resistance, strong adcid and alkali corrosion
resistance, good thermal shock resistance and stable chemical
properties.
4. Inert Ceramic Balls Feature
Alumina balls are made from good quality and high temperature
alumina powder with the characters of high degree purity ,high
intensity high hardness ,more white and less wear abrasion and no
effect for the grinded materials .
Alumina ball is isostatic pressed with high density ,it can
increase grinding efficiency , reduce grinding time and increase
effective volume of grinding mill ,thereby increasing the amount of
grinding material .
Alumina balls have very lower wear resistance can greatly prolong
the service life of grinding medium .
It also have the properties of high temperature resistant ,acid and
alkali resistant ,corrosion resistant . Researched and developed
the alumina balls for dry grinding with the character of lower wear
resistance and good tenacity and solved the problem of materials
pollution from the grinding media .
5. Inert Ceramic Balls Performance Index
| Item/Product | 90 Series | 95 Series | 99 Series | 995 Series |
| Al₂O₃(%) | ≥90 | ≥95 | ≥99 | ≥99.5 |
| Fe₂O₃(%) | ≤0.2 | ≤0.15 | ≤0.1 | ≤0.1 |
| Water Absorption(%) | ≤5 | ≤5 | ≤5 | ≤5 |
| Density(g/cm3) | ≥3.2 | ≥3.4 | ≥3.5 | ≥3.6 |
| Unit Compressive Strength | ≥2000 | ≥3500 | ≥6000 | ≥7000 |
| Φ13mm/(N)) |
| Impact Strength | good | good | good | good |
| Color | White | White | White | White |
6. Inert Ceramic Balls Test
①Factory test
Ceramic alumina balls test is an very important step. Real-time
detection will be carried out in the production process. Alumina
balls produced in each shift will be sampled in large quantities
and tested to ensure the quality of grinding balls.
②The third party test
According to the customer different demand,alumina balls can be
tested by any third party.
7. Inert Ceramic Balls Package
Carton box carton drums plastic bag plastic jumbo bags
8. Factory History
Dragon balls factory are established in 2001.Up to now, we have
cooperated with many large power plants in China for more than 10
years. Since 2007, Dragon balls has set up its own foreign trade
team, and began to show itself to the world. The forged ball, cast
ball ,cylpebs and high alumina balls are widely praised by friends
at home and abroad.
Dragon balls has a very mature technology research and development
team and sales team, we are constantly expanding the factory and
team every year, in order to meet the growing demand at home and
abroad.
Grinding balls are a long-term business.
We are willing to do it all the time because if we know someone, we
will become permanent friends.
We can always do this for so many years because our quality
supports our long-term cooperation and friendship.
The quality of every grinding ball is crucial because it is a
strong bridge that connects us.
