Dragon Balls High Quality Casting Steel Ball Grinding Balls For
Ball Mill
1. Casting balls is popular grinidng media for ball mill, please tell your size,
chrome content or hardness, we will give the most competition
qutation ASAP.
Following is the detail:
2. Casting balls Classification
According to the different chemical elements , Cast balls can be
divided into Low Cr,Medium Cr and High Cr. At present, the above
materials are widely used all over the world, that’s the
conventional materials, if there are special needs, can be
customized.
3. Casting balls Manufacturing process
Casting balls are melted in electric furnace and poured into moulds
after scientific proportioning. High chromium cast balls are also
processed by oil quenching.
4. Casting balls Detail Specifications
① Chemical Composition
Material
|
Chemical Composition |
Low Cr
|
C:2.2-3.4, Si:≤1.2, Mn:0.5-1.5, P:≤0.06, S:≤0.06, Cr:1.0-1.5
|
Medium Cr
|
C:2.0-3.2, Si:<1.0, Mn:0.5-2.5, P:≤0.06, S:≤0.06, Cr:≥5
|
High Cr
|
C:2.0-3.2, Si:<1.0, Mn:0.5-2.5, P:≤0.06, S:≤0.06, Cr:≥10
|
② Hardness
Type
|
Low Cr
|
Medium Cr
|
High Cr
|
20mm-150mm
|
45-50 |
48-55 |
58-63 |
③ Dragon Balls Weight
| Size(mm) | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 | 100 | 110 | 120 | 130 | 140 | 150 |
| Weight(kg) | 0.033 | 0.111 | 0.261 | 0.512 | 0.883 | 1.402 | 2.092 | 2.98 | 1.087 | 5.44 | 7.062 | 9.008 | 11.25 | 13.83 |
5. Casting ballsTest
Casting balls test is an very important step. Real-time detection
will be carried out in the production process. Balls produced in
each shift will be sampled in large quantities and tested for size,
hardness, chemical composition, drop test, core pulling and impact
value to ensure the quality of steel balls.
