Cast Balls Forged Steel Ball Steel Grinding Balls Grinding Media
Balls
1. Dragon Balls Factory have all the kinds of grinding media for
ball mill, forged ball, cast ball, cylpebs, grinding rods .Please
according to the different chemical elements and hardness choose
the material and let us know, we will send the detail ASAP.
2. Forged Steel Grinding Media Balls Chemical Elements
Material |
Chemical Composition |
|
C |
Si |
Mn |
Cr |
P |
S |
Ni |
Cu |
C45 |
0.42-0.5 |
0.17-0.37 |
0.5-0.8 |
≤0.25 |
≤0.035 |
≤0.035 |
≤0.25 |
≤0.25 |
60Mn |
0.55-0.65 |
0.17-0.37 |
0.7-1.0 |
≤0.25 |
<0.04 |
<0.04 |
≤0.3 |
≤0.25 |
B2 |
0.72-0.85 |
0.17-0.37 |
0.7-1.0 |
0.4-0.6 |
≤0.025 |
≤0.025 |
≤0.02 |
≤0.02 |
B3 |
0.58-0.66 |
1.3-1.9 |
0.65-0.8 |
0.7-0.9 |
≤0.025 |
≤0.025 |
≤0.02 |
≤0.02 |
3. Cast Iron Ball,Cylpebs Chemical Elements
| Material | C | Si | Mn | Cr | P | S |
| Low Cr | 2.2-3.4 | ≤1.2 | 0.5-1.5 | 1.0-1.5 | ≤0.06 | ≤0.06 |
| Medium Cr | 2.0-3.2 | <1.0 | 0.5-2.5 | ≥5 | ≤0.06 | ≤0.06 |
| High Cr | 2.0-3.2 | <1.0 | 0.5-2.5 | ≥10 | ≤0.06 | ≤0.06 |
4. Forged Steel Grinding Media Balls Hardness
Size |
C45 |
60Mn |
B2 |
B3 |
| 20mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 30mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 40mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 50mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 60mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 70mm | 53-56 | 58-62 | 60-64 | 61-63 |
| 80mm | 53-56 | 58-62 | 59-63 | 60-65 |
| 90mm | 50-55 | 58-62 | 57-61 | 60-65 |
| 100mm | 48-52 | 57-61 | 56-60 | 60-65 |
| 110mm | 48-52 | 57-61 | 55-60 | 58-64 |
| 120mm | 48-52 | 57-61 | 55-60 | 56-63 |
| 130mm | 48-52 | 57-61 | 55-60 | 56-63 |
| 140mm | 48-52 | 57-61 | 55-60 | 56-63 |
| 150mm | 48-52 | 57-61 | 55-60 | 56-63 |
5. Cast Iron Ball,Cylpebs Hardness
| Type | Low Cr | Medium Cr | High Cr |
| 20mm-150mm | 45-50 | 48-55 | 58-63
|
6. Quality Control
① Factory test
Steel Grinding Balls test is an very important step. Real-time
detection will be carried out in the production process. Balls
produced in each shift will be sampled in large quantities and
tested for size, hardness, chemical composition, drop test, core
pulling and impact value to ensure the quality of steel balls.
② The third party test
According to the customer different demand, steel grinding balls
can be tested by any third party.
7. Packing
Steel Grinding balls are usually packed in container bags and steel
drums, it can also be customized according to different customer
needs.
Steel drums packages for that forged steel grinding media balls
