Forging Steel Ball Cast Iron Ball Cement Grinding Balls Grinding
Media Balls
1. high chromium grinding media balls Classification:
2. high chromium grinding media balls specifications:
① Chemical Composition
| Material | Chemical Composition |
| C | Si | Mn | Cr | P | S | Ni | Cu |
| C45 |
0.42-0.5 |
0.17-0.37 |
0.5-0.8 |
≤0.25 |
≤0.035 |
≤0.035 |
≤0.25 |
≤0.25 |
| 60Mn |
0.55-0.65 |
0.17-0.37 |
0.7-1.0 |
≤0.25 |
<0.04 |
<0.04 |
≤0.3 |
≤0.25 |
| B2 |
0.72-0.85 |
0.17-0.37 |
0.7-1.0 |
0.4-0.6 |
≤0.025 |
≤0.025 |
≤0.02 |
≤0.02 |
| B3 |
0.58-0.66 |
1.3-1.9 |
0.65-0.8 |
0.7-0.9 |
≤0.025 |
≤0.025 |
≤0.02 |
≤0.02 |
② Hardness
Size |
C45 |
60Mn |
B2 |
B3 |
| 20mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 30mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 40mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 50mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 60mm | 55-58 | 58-62 | 60-64 | 62-65 |
| 70mm | 53-56 | 58-62 | 60-64 | 61-63 |
| 80mm | 53-56 | 58-62 | 59-63 | 60-65 |
| 90mm | 50-55 | 58-62 | 57-61 | 60-65 |
| 100mm | 48-52 | 57-61 | 56-60 | 60-65 |
| 110mm | 48-52 | 57-61 | 55-60 | 58-64 |
| 120mm | 48-52 | 57-61 | 55-60 | 56-63 |
| 130mm | 48-52 | 57-61 | 55-60 | 56-63 |
| 140mm | 48-42 | 57-61 | 55-60 | 56-63 |
| 150mm | 48-52 | 57-61 | 55-60 | 56-63 |
③ Weight
| Size(mm) | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 | 100 | 110 | 120 | 130 | 140 | 150 |
| Weight(kg) | 0.033 | 0.111 | 0.261 | 0.512 | 0.883 | 1.402 | 2.092 | 2.98 | 1.087 | 5.44 | 7.062 | 9.008 | 11.25 | 13.83 |
④ Dragon balls specifications
Diameter (mm) | Diameter Tolerance (mm) | Approx Weight of per ball(kg) | Average numbers per ton |
| 20 | ＋1,－0.5 | 0.033 | 30303 |
| 30 | ＋2,－1 | 0.11 | 9090 |
| 40 | ＋2,－1 | 0.261 | 3831 |
| 50 | ＋2,－1 | 0.512 | 1961 |
| 60 | ＋2,－1 | 0.883 | 1132 |
| 70 | ＋3,－1.5 | 1.402 | 713 |
| 80 | ＋3,－1.5 | 2.092 | 478 |
| 90 | ＋3,－1.5 | 2.98 | 335 |
| 100 | ＋3,－1.5 | 1.087 | 244 |
| 110 | ＋3,－1.5 | 5.44 | 183 |
| 120 | ＋3,－1.5 | 7.062 | 141 |
⑤ Grinding rods size
| Diameter | 30mm-90mm |
| Length | 3.2 m-4.5 m |
3. Cast balls, cylpebs Specifications:
① Chemical Composition
| Material | Chemical Composition |
| Low Cr | C:2.2-3.4, Si:≤1.2, Mn:0.5-1.5, P:≤0.06, S:≤0.06, Cr:1.0-1.5 |
| Medium Cr | C:2.0-3.2, Si:<1.0, Mn:0.5-2.5, P:≤0.06, S:≤0.06, Cr:≥5 |
| High Cr | C:2.0-3.2, Si:<1.0, Mn:0.5-2.5, P:≤0.06, S:≤0.06, Cr:≥10 |
② Hardness
| Type | Low Cr | Medium Cr | High Cr |
| 20mm-150mm | 45-50 | 48-55 | 58-63 |
③ Dragon Balls Weight
| Size(mm) | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 | 100 | 110 | 120 | 130 | 140 | 150 |
| Weight(kg) | 0.033 | 0.111 | 0.261 | 0.512 | 0.883 | 1.402 | 2.092 | 2.98 | 1.087 | 5.44 | 7.062 | 9.008 | 11.25 | 13.83 |
④ Dragon balls specifications
Diameter (mm) | Diameter Tolerance (mm) | Approx Weight of per ball(kg) | Average numbers per ton |
| 20 | ＋1,－0.5 | 0.033 | 30303 |
| 30 | ＋2,－1 | 0.11 | 9090 |
| 40 | ＋2,－1 | 0.261 | 3831 |
| 50 | ＋2,－1 | 0.512 | 1961 |
| 60 | ＋2,－1 | 0.883 | 1132 |
| 70 | ＋3,－1.5 | 1.402 | 713 |
| 80 | ＋3,－1.5 | 2.092 | 478 |
| 90 | ＋3,－1.5 | 2.98 | 335 |
| 100 | ＋3,－1.5 | 1.087 | 244 |
| 110 | ＋3,－1.5 | 5.44 | 183 |
| 120 | ＋3,－1.5 | 7.062 | 141 |
⑤ Grinding cylpebs Size(mm)
6×6 |
8×8 |
10×10 |
15×15 |
12×18 |
20×35 |
22×30
|
25×25 |
25×30 |
25×35 |
30×35 |
30×40 |
35×40 |
35×45 |
⑥ Production Process
Cast Balls and cylpebs are melted in electric furnace and poured
into moulds after scientific proportioning. High chromium balls and
cylpebs are also processed by oil quenching.
⑦ The Abrasion of the cast balls when grinding the cement
| Material | Abrasion | Breakage | Size(mm) |
| Low Chrome Cast Ball | 85-105g Cast Balls /Ton Cement | <2% | 10-150mm |
| Medium Chrome Cast Ball | 50-80g Cast Balls /Ton Cement | <1.5% | 10-150mm |
| High Chrome Cast Ball | 35-60g Cast Balls/Ton Cement | <1% | 10-120mm |
| High Chrome Cylpebs | 35-60g Cylpebs/Ton Cement | <1.5% | 12×18-35×40 |
| Low Chrome Cylpebs | 65-95g Cylpebs/Ton Cement | <1% | 12×18-35×40 |
| Micro Cylpebs | 6×6 8×8 10×10 12×12 15×15 |
4. The difference of the forged ball and cast ball
① Different production line
② Different raw material
③ Different chemical element
④ Different core hardness and core hardness
5. Packing
Cylpebs are usually packed in container bags and steel drums, it
can also be customized according to different customer needs.
